Technical Data
46 3A0732U
Technical Data
Maximum fluid working pressure
15:1 Pumps 1500 psi (10.3 MPa, 103 bar)
30:1 Pumps 3000 psi (20.7 MPa, 207 bar)
Maximum air inlet pressure 100 psi (0.7 MPa, 7.0 bar)
Ratio
15:1 or 30:1 (see Models, page 3)
Maximum fluid temperature. 160°F, 71°C
Ambient air temperature range 35-120°F, 2-49°C
Package air inlet size 3/8 npt(f)
Package fluid outlet size 1/4 npsm(m)
Maximum motor speed 240 cycles per minute
(Do not exceed maximum recommended speed of fluid pump, to prevent premature pump wear.)
Maximum spray tip orifice size 019 in. (0.483 mm)
Sound data
24G693 Air Motor
Sound power* 83.2 dBA
Sound pressure* 76.5
24G694 Air Motor
Sound pressure** 77.9 dBA
Sound power* 84.5 dBA
Wetted parts
Plated steel pumps with v-packings Stainless steel, nickel plated carbon steel,
tungsten carbide, ptfe, acetal, leather, ultra-high
molecular weight polyethylene
Stainless steel pumps with v-packings Stainless steel, tungsten carbide, ptfe, acetal,
leather, ultra-high molecular weight polyethylene
Plated steel pumps with u-cups Stainless steel, nickel plated carbon steel,
tungsten carbide, ptfe, acetal, ultra-high molecular
weight polyethylene
Spray guns See manual 3A8099
Fluid hose Nylon, plated or stainless steel
Suction Assembly Stainless steel, nylon, acetal, fluoroelastomer,
polyethylene
* Sound power at 70 psi (0.48 MPa, 4.8 bar), 80 cpm. Sound power measured per ISO-9614-2.
** Sound pressure was tested 3.28 feet (1 m) from equipment.
