Package Parts 30:1 Ratio Pumps
Ref.
No.
Description
Package
Qty
24F152 24F153 24W287 24F154 24F155 24F156 24F157 24W285
1 BRACKET, wall 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 1
2 KIT, stand; includes items
3, 4, 5, 6, and 43 below,
and 418 on page 40
24F164 24F164 24F164 24F164 24F164 1
3 PLUG 108175 108175 108175 108175 108175 4
4 SCREW, cap, hex hd;
1/4-20 x 1.5 in. (38 mm)
100058 100058 100058 100058 100058 6
5 SPACER, tube --- --- --- --- --- 4
6 NUT, hex; 1/4-20 100015 100015 100015 100015 100015 6
7 MOTOR, air; see page 36 24G694 24G694 24G694 24G694 24G694 24G694 24G694 24G694 1
8 KIT, rod, tie; includes rods
and items 11 and 17 (3 of
each)
24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 1
9 SPRING, safety 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 1
10 ADAPTER, pump lower 24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 1
11 NUT, lock 104541 104541 104541 104541 104541 104541 104541 104541 3
12 LOWER, pump; see page
33;
also includes items 15, 18,
and 19
24G702 24G702 24G702 24G701 24G701 24G701 24G701 24G701 1
13 NUT, jam 195150 195150 195150 195150 195150 195150 195150 195150 1
15‡ NIPPLE; 1/4 npsm x 1/4
npt; plated steel
162453 162453 162453 162453 162453 1
NIPPLE; 1/4 npsm x 1/4
npt; sst
166846 166846 166846
1
16 KIT, suction hose, 5 gal.
(19 l);
3/8 in. (10 mm) OD;
includes items 37 (qty 1),
38, and 42
24F148 24F148
24F148 24F148 24F148 24F148 1
17 NUT, hex; 7/16-20 Not sold separately. Order Tie Rod Kit, item 8. 3
18‡ PIN, straight 196762 196762 196762 196762 196762 196762 196762 196762 1
19‡ SPRING, retaining 196750 196750 196750 196750 196750 196750 196750 196750 1
20 AIR CONTROL
ASSEMBLY; see page 40
24H162 24H163 24H163 24H164 24H165 24H162 24H163 24H163 1
21 ELBOW, swivel; 1/4 npt(m)
x 3/8 in. (10 mm) OD tube
121141 121141 121141 121141 121141 121141 121141 121141 1
22 TUBE, polyurethane; 3/8
in. (10 mm) OD;
2 ft (0.61 m)
24H008 24H008 24H008 24H008 24H008 24H008 24H008 24H008 1
23 SCREW, ground 116343 116343 116343 116343 116343 116343 116343 116343 1
26 WIRE, grounding 238909 238909 238909 238909 238909 238909 238909 238909 1
‡ Included in Pump Lower Rebuild Kit. See page 42.
* Not shown. See Merkur ES Hopper Kit manual 334011 for more information.
