Graco 24F150 User Manual

Parts
3A0732U 37
Air Motor Parts
Part No. 24G693, 2.5 in. (63.5 mm)
Part No. 24G694, 3.5 in. (88.9 mm), shown
▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.
† Included in Air Valve Seal Kit 24A535. See page 39.
◆ Included in Air Valve Repair Kit 24A537. See page 39.
* Included in Air Motor Seal Kit:
Ref. Description 24G693 24G694 Qty
201 KIT, cover, bottom; includes 202 (qty 1),
203, 207, 213 (qty 1), and 217
24G695 24G696 1
202* O-RING, cover Not sold separately. See Air Motor Seal Kit (below), Bottom Cover Kit
(201, this table), or Top Cover Kit (210, this table)
2
203 BEARING Not sold separately. See Bottom Cover Kit (201, this table) 1
204* O-RING, piston Not sold separately. See Air Motor Seal Kit (below) or
Piston Kit (219, this table)
1
205 CYLINDER, motor 15M289 15M211 1
206
▲
COVER, cylinder (includes English
warning label)
15M302 15M212 1
207* SEAL, u-cup Not sold separately. See Air Motor Seal Kit (below) or
Bottom Cover Kit (201, this table)
2
208* GASKET, manifold Not sold separately. See Air Motor Seal Kit (below) or
Manifold Assembly (220, this table)
2
209*
◆ †
GASKET, air valve Not sold separately. See Air Motor Seal Kit, Valve Repair Kit 24A537,
Valve Seal Kit 24A535 (below), or Manifold Assembly (220, this table)
1
210 KIT, cover, top; includes 202 and 213
(qty 1 of each). 15X353 also includes
230 and 231.
24H004 15X353 1
211 SCREW, M6 x 25 Not sold separately. See Manifold Assembly (220, this table) or
Air Valve Replacement Kit (page 39)
8
212 BOLT, tie, hex head 15M314
2
BOLT, tie, hex head
15M314 3
213 VALVE, pilot (pack of 2) 24A366 24A366 1
214 VALVE, air; includes items 209 and 211
(qty 4)
24A351 24A351 1
215 MUFFLER 15M213 15M213 1
217* RING, retaining Not sold separately. See Air Motor Seal Kit (below) or
Bottom Cover Kit (201, this table)
1
218 ROD, air motor Not sold separately. See Motor Piston Kit (219, this table) 1
219 KIT, piston, motor; includes 204 and
218, and 16G561 adhesive.
24G697 24G698 1
220 MANIFOLD, assembly, includes 208,
209, and 211 (qty. 4)
24A579 24A579 1
229
▲
LABEL, warning (French and Spanish) 15W719 15W719 1
230* O-RING, top plug (24G694 only)
Not sold separately. See Air
Motor Seal Kit (below)
1
231 PLUG, top cover (24G694 only)
Not sold separately. See Top
Cover Kit (210, this table)
1
24G693
(2.5 in. Motor)
24G694
(3.5 in. Motor)
24G699 24G700
