Parts

3A0732U 41

Air Control Parts

Part No. 24H162, Air-Assisted, Wall Mount

Part No. 24H163, Air-Assisted, Stand Mount

Part No. 24H164, Airless, Wall Mount

Part No. 24H165, Airless, Stand Mount

Ref Description 24H162 24H163 24H164 24H165 Qty

401 BRACKET, handle 24H105 24H105 24H105 24H105 1

402 REGULATOR, air 15T499 15T499

REGULATOR, air

15T499 15T499 1

403 TEE; 1/4 npt(m) 115219 115219

404 GAUGE, air pressure 108190 108190 2

GAUGE, air pressure 108190 108190 1

405 ELBOW, tube; 1/4 npt(f) x 3/8 in. (10 mm) OD tube C38161 C38161

FITTING, tube; 1/4 npt(m) x 3/8 in. (10 mm) OD tube

120389 120389 1

406 TUBE, polyurethane; 3/8 in. (10 mm) OD tube; 2 ft (0.61 m) 24H008 24H008 24H008 24H008 1

407 VALVE, ball, air; 3/8 npt(fbe) 114362 114362 114362 114362 1

408 NIPPLE; 1/4 npsm x 1/4 npt 162453 162453

409 ELBOW, swivel; 3/8 npt(m) x 3/8 in. (10 mm) OD tube 16F151 16F151 16F151 16F151 1

410 ELBOW; 1/4 npt(f) x 1/8 npt(m) 121150 121150 121150 121150 1

411 VALVE, safety relief; 110 psi 113498 113498 113498 113498 1

412 ELBOW, swivel; 1/4 npt(m) x 3/8 in. (10 mm) OD tube 121141 121141 121141 121141 1

413 NUT, regulator 115244 115244

NUT, regulator

115244 115244 1

418 ELBOW, street, 45°; 1/8 npt (mxf)

113630 2

ELBOW, street, 45°; 1/8 npt (mxf) 113630 1

420 SCREW, cap, button-hd; 10-24 x 3/8 in. (10 mm) 114381 114381 114381 114381 2

421 PLUG, panel

16F547 16F547 1

422 RING, grounding 24P812 24P812 24P812 24P812 1
