Graco 256282 - Nozzle Kits and Thermal Relief Kits

Nozzle (33) and Extension (20) Kits
32 313046A
Nozzle (33) Kits
Thermal Relief Kits (page 4)
255459* Automatic, non-drip, quick-close nozzle Qty Oil
• BODY, nozzle 1
• O-RING, packing 1
• SPRING, compression 1
• O-RING, packing 1
• STEM, nozzle, valve 1
• SEAT, valve 1
255460* Automatic, non-drip, quick-close nozzle Anti-freeze
• BODY, nozzle 1
• SPRING, compression 1
• O-RING, packing 1
• STEM, nozzle, valve 1
• O-RING, packing 1
• SEAT, valve 1
255461 Automatic, non-drip, high-flow nozzle Oil and Antifreeze
• STEM, nozzle 1
• BODY, nozzle 1
• O-RING, packing 1
• O-RING, packing 1
• O-RING, packing 1
255470 Non-drip, quick-close nozzle Gear Lube
• Housing 1
• Body, nozzle 1
• O-RING, packing 1
• O-RING, packing 1
• Plug, Hollow, hex 1
*Used for dispensing 5gpm (22.7 lpm) or less.
Part No. Description PSI (bar) Rating
112353 Diaphragm pump for fuel dispense, valve only 50 psi (3.4 bar)
235998
Mini Fire-Ball
™
225, 3:1
600 psi (41 bar)
237601 Fire-Ball 425, 3:1 600 psi (41 bar)
237893 Mini Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1 900 psi (62 bar)
248296
Mini Fire-Ball 300, 5:1 and Fire-Ball 425, 6:1
(same as 237893 without bung adapter and
swivel. Includes 6-foot hose)
900 psi (62 bar)
238899 Diaphragm pump 150 psi (10.4 bar)
240429 Fire-Ball 425, 10:1 1600 psi (110 bar)
248324
Fire-Ball 425, 10:1 (same as 240429 minus bung
adapter and swivel. Includes 6-foot hose)
1600 psi (110 bar)
