Shutdow
n and Clea
ning
20
3A178
2D
Cleaning Gu
n Filter
Perf
orm
Pres
sure Relief
Procedure
, page 11.
1.
Engage gu
n trigger
lock.
2.
Unscrew hos
e.
3.
Remov
e filter an
d clean i
t in compati
ble solven
t.
NOTE:
Do not so
ak entire gun in s
olvent. Pr
olonged
expo
sure to so
lvent
can ruin pa
ckings
.
4.
In
sert filter
and torque
to 26-32 f
t-lb.
ti8908
a
ti1723
5a
ti174
99a
ti1749
9a
19
21
