Component Identification
8 3A1782D
Component Identification
A Airless spray gun Dispenses fluid.
B Power switch Turns sprayer ON and OFF.
C Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid pressure in
pump, hose, and spray gun.
C1 Setting Indicator To select function, align symbol on pressure control knob with setting
indicator, page 11.
D Pump fluid outlet fitting Threaded connection for paint hose.
G Suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve • PRIME position directs fluid to prime tube.
• SPRAY position directs pressurized fluid to paint hose.
• Automatically relieves system pressure in overpressure situations.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
N Handle Used to help transport sprayer.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and controls fluid flow
according to hole size.
• Reverse unclogs plugged tips without disassembly.
S Gun trigger safety lever
(page 11)
Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
V Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
X Power cord Supplies sprayer with electricity
Z Pump priming button Manually taps inlet ball to loosen if stuck.
AA Plug Adapter Adapts power cord to Australian electrical outlet.
AB Plug Adapter Retainer Retains plug adapter to power cord.
