Repair
3A0411A 13
FIG. 3. Ball check valve assembly
Torque to 40-45 ft-lb (54-61 N•m) for Polypropylene models.
Torque to 55-60 ft-lb (75-81 N•m) for Aluminum models.
Torque to 40-45 ft-lb (54-61 N•m) for Stainless Steel models.
See Torque Instructions, page 20.
1
Not used on some models.
3
ti17808a
8
3
23
10
Arrow (A) must point toward outlet manifold.
2
1
3
Polypropylene
pump shown
7
1
9
9
12
11
13
13
10
9
8
9
12
13
13
11
A
3
2
3
3
