Parts/Kits Quick Reference
3A0411A 25
Parts/Kits Quick Reference
Use this table as a quick reference for parts/kits. See pages indicated in table for full description of kit contents.
Ref. Part/Kit Description
1a CENTER SECTION, not sold separately, see
page 27
----- Aluminum
----- Polypropylene
1b AIR VALVE; see page 30
2 FLUID COVER KITS; see page 32
24K871 Aluminum
24K873 Polypropylene
24K876 Stainless Steel
3 MANIFOLD, outlet elbow kits; see page 32.
24K885 Aluminum
24K888 Polypropylene
24K892 Stainless Steel
4 MANIFOLD, inlet elbow kits; see page 32.
24K886 Aluminum
24K889 Polypropylene
24K893 Stainless Steel
5 MANIFOLD, center kits, see page 32.
24K884 Aluminum, npt
24K969 Aluminum, bspt
24K890 Polypropylene
24K894 Stainless Steel, npt
24K970 Stainless Steel, bspt
6 SEAL, manifold joint, see page 37
24K880 Buna-N, for aluminum and poly
24K879 PTFE, for aluminum and poly
24K882 PTFE, for stainless steel
7 BOLTS, manifold elbows to center; not used
on stainless steel, see page 32
24K887 Aluminum
24K891 Polypropylene
8 FASTENERS, manifold to fluid cover, see
page 33
24K956 Aluminum
24K883 Polypropylene
24K896 Stainless Steel
9 ----- WASHER, included with fastener kits
10 ----- NUT, included with refs 36 and 37
11 SEATS; 4-pack, see page 34
24K928 Acetal
24K929 Aluminum
24K930 Buna-N
24K936 FKM Fluoroelastomer
24K931 Geolast
24K933 Polypropylene
24K934 Santoprene
24K935 Stainless Steel
24K932 TPE
12 CHECK BALLS; 4-pack, see page 34
24K937 Acetal
24K938 Buna-N
24K941 Polychloroprene, standard
24K942 Polychloroprene, weighted
24K945 FKM Fluoroelastomer
24K939 Geolast
24K943 PTFE
24K944 Santoprene
24K940 TPE
13 O-RING, seat (not used on some models);
8-pack, see page 37
24K909 Buna-N
24K927 PTFE
14 24K975 PLATE, air side diaphragm, includes o-ring
(17) and washer (18)
15 PLATE, fluid side diaphragm, see page 36
24K906 Aluminum
24K907 Polypropylene
24K908 Stainless steel
16 ----- SCREW, hex washer head,
3/8-11x 3 in., carbon steel, included with Ref.
15
17 ----- O-RING, included with Refs. 14 and 15
18 ----- WASHER, included with Refs. 14 and 15
20 DIAPHRAGM Kits; see page 35
24K897 Buna-N Standard
24K903 FKM Standard
24K900 Geolast Standard
24K898 Polychloroprene Overmolded
24K904 Polychloroprene Standard
24K899 PTFE Overmolded
24K905 PTFE/Santoprene Two-Piece
24K902 Santoprene Standard
24K901 TPE Standard
Continued
Ref. Part/Kit Description
