Spraying
26 3A6342A
Clear Spray Tip Clog
In the event that particles or debris clog the
Spray Tip, the Spray Tip can be reversed to
quickly and easily clear particles without
disassembling the sprayer.
See Strain the Paint, page 21 for additional
information.
1. Engage Trigger Lock. Rotate Spray Tip
to UNCLOG position. Ensure spray tip
remains fully seated, pushed all the way
into the Spray Tip Guard. Disengage
Trigger Lock. Trigger Spray Gun at
waste area to clear clog.
NOTE: If Spray Tip is difficult to rotate when
turning to the UNCLOG position perform,
Pressure Relief Procedure, page 19, then
turn Prime/Spray Valve horizontal to SPRAY
position and repeat step 1.
2. Engage Trigger Lock. Rotate Spray Tip
back to SPRAY position. Disengage
Trigger Lock and continue spraying.
Spray Tip Installation
To prevent Spray Tip leaks make certain
Spray Tip and Spray Tip Guard are installed
properly. Refer to separate Spray Gun
manual for procedure to remove and install
Spray Tip, Seal, and Spray Tip Guard.
To avoid serious injury from skin injection
do not put your hand in front of the spray tip
when installing or removing the spray tip
and spray tip guard.
