Maintenance
3A6342A 35
Maintenance
Routine maintenance is important to ensure proper operation of your sprayer. Maintenance
includes performing routine actions which keep your sprayer in operation and prevents trouble
in the future.
Perform Pressure Relief Procedure, page
19 before performing maintenance.
Maintenance can be scheduled and tracked
via the Graco BlueLink app. See
Maintenance, page 35 for more information.
Recycling and Disposal at
End of Life
At the end of the product’s useful life,
dismantle and recycle it in a responsible
manner.
Preparation:
•
Perform the Pressure Relief
Procedure, page 19.
• Drain and dispose of fluids according to
applicable regulations. Refer to the
material manufacturer’s Safety Data
Sheet.
Dismantle and recycle:
•
Remove motors, circuit boards,
displays, and other electronic
components. Remove the coin-cell
battery from the battery holder on the
control board. Recycle according to
applicable regulations.
• Do not dispose of electronic
components with household or
commercial waste.
• Deliver remaining product to a recycling
facility.
Activity Interval
Inspect/clean sprayer filter, fluid inlet strainer, and Spray Gun
filter.
Daily or each time you spray
Inspect motor shield vents for blockage.
Daily or each time you spray
Fill TSL by adding through TSL fill point.
Daily or each time you spray
Check sprayer stall.
With sprayer Spray Gun NOT triggered, sprayer motor should
stall and not restart until Spray Gun is triggered again.
If sprayer starts again with Spray Gun NOT triggered, inspect
pump for internal/external leaks and check prime valve for
leaks.
Every 1000 gallons (3785 liters)
Throat packing adjustment
When pump packing begins to leak after extended use, tighten
packing nut down until leakage stops or lessens. This allows
approximately 100 gallons of additional operation before a
repacking is required. Packing nut can be tightened without
0-ring removal.
As necessary based on usage
