10 309242
Shutdown
Pressure Relief Procedure
WARNING
PRESSURIZED EQUIPMENT HAZARD
The equipment stays pressurized until pressure is
manually relieved. To reduce the risk of a serious
injury from pressurized fluid, accidental spray from
the gun, or splashing fluid, follow the Pressure
Relief Procedure whenever you:
D Are instructed to relieve the pressure
D Stop spraying
D Check or service any of the system equipment
D Install or clean the fluid nozzles
1. Turn off air supply to gun.
2. Turn off turbine sprayer.
WARNING
The turbine hose outlet may be hot. Carefully check
the hose end before you remove the hose.
3. If using remote pressure pot, relieve pressure by
following the pressure relief procedure on page 8.
NOTE: Elevate spray gun and pull trigger. This will
allow fluid in fluid hose to drain back into remote
pressure pot.
4. If using a spray gun cup, unlatch cup cover;
loosen or remove cup from cover to relieve cup
pressure.
5. Clean spray gun and cup as instructed in the
HVLP–Turbine Gun manual 309205.
