14 309242
Repair
WARNING
Turn off turbine and unplug power for the following
procedures.
Turbine Sprayer Disassembly (unless
otherwise indicated, refer to Fig. 8 and 9).
1. If necessary, clean and replace filter according to
maintenance procedure on page 11.
2. Loosen the four thumbscrews (16), remove the
filter retainer (15) prefilter (22) and main filter (21).
See Parts Drawing on page 18.
3. Remove hose clamp (88) and disconnect the air
hose (84 ) from the “out” side of the compressor
(64 ).
4. Disconnect the compressor wiring harness (a)
from the compressor (64 )
5. Remove the four cap screws (27) and bumpers
(7).
6. Place the turbine on its back. Carefully separate
the turbine cover (1) from the turbine baseplate (2)
while guiding the compressor air hose (84) and
wiring harness (a) through the air passage (b) in
turbine cover (1). Place the turbine baseplate
upright on a work surface.
7. Repair or replace items as required.
8. After completing servicing place turbine baseplate
(2) on its back.
9. Slide turbine cover (1) onto turbine baseplate
approximately 1–2 in. (to get it started).
10. Reaching between the turbine cover (1) and base-
plate (2) carefully guide the compressor air hose
(84) and wiring harness (a) through air passage (b)
through the compressor mounts (c) in the turbine
cover (1).
11. Gently pull the free ends of the compressor air
hose (84) and wiring harness (a) with your other
hand to take up the slack.
12. Maintain tension on the compressor air hose (84)
and wiring harness and slide the turbine cover (1)
fully onto the turbine base plate.
13. Replace four capscrews (27) and bumpers (7).
14. Reconnect compressor air hose (84) and wiring
harness (a).
CAUTION: Keep excess tubing and wiring clear of
compressor cooling fan (d) by securing to compressor
mount (c) with wire tie (e).
15. Reassemble filter, filter retainer, and prefilter.
