General Information
HVLP ProCompt Turbine Sprayers
The HVLP 3800 ProCompt and the HVLP 4900
ProCompt turbines, compressor and spray guns can
spray most coatings or finishes currently being used
for automotive refinish, industrial, aerospace, marine,
wood, plastic, and architectural applications.
To produce high-quality paint finishes, the spray gun
typically utilizes inbound air pressure of 6 psi (0.4 bar,
41 kPa) for the HVLP 3800 ProCompt and 8 psi (0.5
bar, 55 kPa) for the HVLP 4900 ProCompt. A cone of
air, produced by the gun, carries and directs the paint
from the gun to the surface, minimizing overspray and
increasing transfer efficiency. This enables painters to
comply with new clean air laws that are designed to
reduce VOC (volatile organic compounds) emissions,
eases paint application by requiring fewer paint passes
to obtain coverage, and saves on both material and
clean-up time.
See HVLP–Turbine Gun manual 309205 for more
information on the operation and use of the turbine
spray gun.
Unpacking Turbine
Unpack the Graco Turbine Sprayer from the shipping
carton, and inspect for any possible shipping damage.
If there is any damage, call your distributor.
HVLP ProCompt Turbine Configurations
Graco turbines come in the following basic configura-
tions:
D HVLP 3800 ProCompt three-stage turbine sprayer
D HVLP 4900 ProCompt four-stage turbine sprayer
HVLP 3800 and 4900 ProCompt Turbine Components Table
System Model 2–qt Remote
Pressure Pot
30-ft (9 m) Turbine
Air Hose
30-ft (9 m) Com-
pressor Air Hose
Gun /
Fluid Set
Extra/Fluid
Sets
HVLP 3800
ProCompt
233423 287819 241413
240071
244118 non-
bleeder style
pressure–fed gun
with 244124 (#3)
244125 (#4)
244126 (#5)
HVLP 4900
ProCompt
233455 287819 241413
240071
244118 non-
bleeder style
pressure–fed gun
with 244124 (#3)
244123 (#2)
244125 (#4)
244126 (#5)
244127 (#6)
