System Configuration and Part Numbers
4 312776K
System Configuration and Part Numbers
Configurator Key
The configured part number for your equipment is printed on the equipment identification labels. See FIG. 1
for location of the identification labels. The part number includes one digit from each of the following six
categories, depending on the configuration of your system.
Manual
System Control and Display A and B Meter Color Valves Catalyst Valves Applicator Handling
M D = EasyKey with LCD
Display
0 = No Meters
1 = G3000 (A and B)
2 = G3000HR (A and
B)
3 = 1/8 in. Coriolis (A)
and G3000 (B)
4 = G3000 (A) and 1/8
in. Coriolis (B)
5 = 1/8 in. Coriolis (A)
and G3000HR (B)
6 = G3000HR (A) and
1/8 in. Coriolis (B)
7 = 1/8 in. Coriolis (A
and B)
0 = No Valves
(single color)
1 = Two Valves
(low pressure)
2 = Four Valves (low
pressure)
3 = Seven Valves
(low pressure)
4 = Twelve Valves
(low pressure)
5 = Two Valves
(high pressure)
6 = Four Valves
(high pressure)
0 = No Valves
(single catalyst)
1 = Two Valves
(low pressure)
2 = Four Valves
(low pressure)
3 = Two Valves
(high pressure)
1 = One Air Flow
Switch Kit
2 = Two Air Flow
Switch Kits
3 = One Gun Flush Box
Kit
4 = Two Gun Flush Box
Kits
M
(acid
models)
E = EasyKey with LCD
Display
1 = G3000 (A) and
G3000A (B)
0 = No Valves
(no color; need
to order acid kit
26A096-26A100;
see page 6)
0 = No Valves
(single catalyst)
1 = One Air Flow
Switch Kit
2 = Two Air Flow
Switch Kits
3 = One Gun Flush Box
Kit
4 = Two Gun Flush Box
Kits
To Next Page
