Graco Reactor 2 E-XP2 User Manual

Models
Reactor 2 E-XP
2 and E-XP2 Elite
All elite systems include fluid inlet sensors and Xtreme-Wrap 50 ft (15 m) heated hose. For part numbers, see
Accessories, page 11
E–XP2 Model E–XP2 Elite Model
Model
15 kW 15 kW
Proportione
r ★
272012 272112
Maximum Flui
d Working
Pressure psi
(MPa, bar)
3500 (24.1, 241) 3500 (24.1, 241)
Approximate Output per
Cycle (A+B) gal. (liter)
0.0203 (0.0771) 0.0203 (0.0771)
Max Flow Rategpm/min
(l/min)
2 (7.6) 2 (7.6)
Total System Load † ◊
(Watts)
23,000 23,000
Configura
ble Voltage
Phase ◊
200–240
VAC 1Ø
200–240
VAC 3Ø∆
350–415
VAC 3ØY
200–240
VAC 1Ø
200–240
VAC 3Ø∆
350–415
VAC 3ØY
Full Load Peak Current
(amps)
100 62 35 100 62 35
Fusion AP Package ‡
(Gun Part No.)
AP2012
(246100)
AP2112
(246100)
Probler P2 Package ‡
(Gun Part No.)
P22012
(GCP2R1)
P22112
(GCP2R1)
Heated Hose
50 ft (15 m)
24K241
(scuff guard)
24Y241
(Xtreme-Wrap)
Heated Whip Hose
10 ft (3 m)
246055 246055
Flui
d Inlet Sensors (2)
✓
Ratio Monitor
✓
*
Full load amps with all devices operating at
maximum capabilities. Fuse requirements
at various flow rates and mix chamber sizes
may be less.
†
Tot
al system watts used by system, based on
max
imum heated hose length for each unit.
• E–30 and E–XP2 series: 310 ft (94.5 m)
maximum heated hose length, including
whip hose.
★
Se
e Approvals, page 11.
‡
Packages include gun, heated hose, and
whip hose. Elite packages also include fluid
inlet sensors.
◊
Low
line input voltage will reduce power
ava
ilable and heaters will not perform at full
cap
acity.
Vol
tage Configurations Key
Ø
Phase
∆
DELTA
YWYE
10 333024N
