Parts
Quantity
Ref
Part Description
24U320 25N920
601 160327
FITTING, union adapter, 90°
22
602 118459
FITTING, union, swivel, 3/4 in.
22
603‡ 247503
MANIFOLD, s
trainer, inlet
22
604 24U852
THERMOMETER, dial
22
605 24U853
GAUGE, press, fluid
22
606†
---
FILTER, replacement 2 2
607†‡ 128061
PACKING, o-ring
22
608‡ 16V879
CAP, filt
er
22
609‡ 555808
PLUG, 1/4mp w/ hex hd
22
610 15D757
HOUSING, thermometer, Viscon HP
22
613 109077 VALVE, ball 3/4 npt 1 2
614
C20487 FITTING, nipple, hex
22
615 24U851
TRAN
SDUCER, pressure, temperature (includes foam)
2
616 158586
FITTING, bushing
2
617 158
383
FITTING, union adapter
2
618 624545
FI
TTING, tee 3/4m run x 1/4f
2
* Optional 80 mesh filter 255082 (2 pack)
†
Included in 24V020 Inlet Filter and Seal Kit, 20 mesh (2 pack).
‡
Included in 247503 Manifold Repair Kit.
333024N 105
