Graco Reactor 2 E-XP2 User Manual

Parts
25N930
Ref
Part Description
Qty.
701
---
HOUSING, 3/4" orb, w/ pins, sub-assembly
1
703
25C298 GEAR, magnets, sd/matrix
1
704
15V690PKG GEAR, oval, metering element
1
705
17Y063PKG GASKET, meter
1
706
131971PKG O-RING, 031, fx75
1
707
17Y062PKG CAP, meter
1
708 108787
SCREW, cap, sch
8
709
110163PKG SCREW, thd forming, pnh
2
710
25E134PKG BOARD, assembly, ratio monitor
1
711
---
COVER, meter
1
712 131172
SCREW, mach, torx pan hd
4
25E486PKG FITTING, swivel, JIC-08, 3/4-16 orb, A-side, ISO
1
716
25E474PKG FITTING, swivel, JIC, 10 x 3/4-16 orb, B-side, RES
1
117677
FITTING, reducer #6 x #10 (JIC), B-side, RES
1717
117502
FITTING, reducer #5 x #8 (JIC), A-side, ISO
1
718
---
LABEL, blank 1
719
---
LABEL, branding, G-2000
1
720 070268
LUBRICANT, grease
1
17Y236
FITTING, adapter, sae-orb x JIC, A-side, ISO
1721
17Y235
ADAPTER, str thread, B-side, RES
1
722 070408
SEALANT, pipe, sst
1
▲
Replace
ment Warning labels, signs, tags, and cards are available at no cost.
94 333024N
