Parts
Fluid Manifol
d
24U844
1
Torque to 355–395 in.-lbs (40–44.6 N●m)
2
Apply sealant (113500) to threads.
3
Valve must be closed with handle position as
shown on drawing.
4
Apply
PTFE tape and thread sealant to gauge
threa
ds.
5
Apply grease on valve.
**
Appl
y PTFE tape or thread sealant to tapered
thre
ads.
