Troubleshooting
Pumps Pumps
Pumps
Do Do
Do
Not Not
Not
Reverse Reverse
Reverse
Direction Direction
Direction
Forproportioningpumpstoreversedirection,the
proximityswitches(211)mustsensetheswitching
plate(319)toreversethedirectionalvalve(207).
Voltageisstillpresentinsidethedirectional
valve.Impropertestingoftheproximityswitch
connectionsinsidethedirectionalvalvemay
causeinjuryorelectricshock.Checkthe
proximityswitchconnectionsasinstructed.
Measurevoltageacrosscorrectterminals.See
ElectricalSchematics,page94.
Theswitchingplatemovesfromsidetosideduring
operation.Keephandsawayfromtheswitching
plate,whilecheckingthefunctionalityofthe
directionalvalve,topreventpinchinghands.
1.Checkthefunctionalityofeachproximityswitch
(211).
a.Removethefrontcover.
b.Withthemotorpoweredoff,con󰘰rmthatthe
indicatinglightsonthebodyofeachproximity
switch(211)turnsonwhenametallicitem,
suchastheshaftofascrewdriver,isplaced
onthefaceofeachswitch.
c.Iftheindicatinglightsturnon,theproximity
switches,itswiring,andtheHCMarelikely
operatingcorrectly;proceedtostep2.Ifthe
indicatinglightsdonotturnon,proceedto
step6.
2.Con󰘰rmtheproximityswitches(211),switch
bracket(209),andswitchingplate(319)are
󰘰rmlymountedandnotdamaged.
3.Checkdistancebetweentheproximityswitches
(211)andtheswitchingplate(319).
a.Parkthepump.
b.Con󰘰rmthattheproximityswitch(211)
nearesttheA-sideofthepumpisbackedout
0.5to1.5turnsfrombeingincontactwiththe
switchingplate(319).
c.Disconnectthecablefromtheproximity
switch(211)nearesttheB-sideofthepump.
Operatethepumpuntiltheswitchingplate
(319)islocatedabovetheB-sideproximity
switch,thenturnoffthemotor/pump.
d.Con󰘰rmthattheproximityswitch(211)
nearesttheB-sideofthepumpisbackedout
0.5to1.5turnsfrombeingincontactwiththe
switchingplate(319).
e.ReconnectthecabletotheB-sideproximity
switch(219).
4.Checkfunctionalityofthedirectionalvalve(207).
a.Con󰘰rmthatthedirectionalvalvecable
isconnectedproperlyfromHCMport15
tothedirectionalvalvebody(207)and
isnotdamaged.Inspectwiringinside
thecoverofthedirectionalvalve.See
ElectricalSchematics,page94.
b.Duringoperation,thedirectionindicatorlights
onthedirectionalvalvebody(207)should
switchonbasedonthevalvethatisopen.
334946C
41
