Repair

Replace Replace

Replace

Electric Electric

Electric

Motor Motor

Motor

Remove Remove

Remove

NOTICE NOTICE

NOTICE

Topreventdroppingtheelectricmotor,twopeople

mayberequiredtoremovethemotorfromthe

system.

1.FollowShutdown,page49.

2.Openelectricalenclosure.Disconnectthe

AsideheaterconnectorfromtheTCM.See

ElectricalSchematics,page94.Closethe

electricalenclosuredoor.

3.Removemountingboltsfromthebottomframe

andmovethesystemawayfromthewall.

Figure2

4.Removeupperbolts(3).Tilttheelectrical

enclosuredowntogainaccesstothemotor

cover.

5.Removemotorandbeltcovers(123,131,132).

Liftcover(132)andloosenthebluebracket(131)

fasteners.Liftthebluebracket(133)offofthe

fastenersandsetaside.Removethebeltcovers

(131,132).

Figure3MotorandBeltCovers

Figure4HeaterandBeltCovers

54 334946C
