Graco Reactor E-10 User Manual

Setup
16 311075R
Table 2: Electrical Requirements
Model Required Power Source Power Cord Connector
120 V, 1 phase, 50/60 Hz, two
15 ft (4.5 m) power cords,
Heated
Two separate, dedicated cir-
cuits rated at minimum of 15
A each
240 V, 1 phase, 50/60 Hz, two
15 ft (4.5 m) power cords,
Heated
Two separate, dedicated cir-
cuits rated at minimum of 10
A each
240 V, 1 phase, 50/60 Hz, one
15 ft (4.5 m) power cord,
Heated
Single dedicated circuit rated
at minimum of 16 A
120 V, 1 phase, 50/60 Hz, one
15 ft (4.5 m) power cord, Non-
heated
Single dedicated circuit rated
at minimum of 15 A
240 V, 1 phase, 50/60 Hz, one
15 ft (4.5 m) power cord, Non-
heated
Single dedicated circuit rated
at minimum of 8 A
Two NEMA 5-15T
Two IEC 320, with
two local adapters:
Euro CEE74 Adapter
Australia/China Adapter
One NEMA 6-20P
One NEMA 5-15T
One NEMA 6-20P
Table 3: Extension Cord Requirements
Model
Required Wire Size
Up to 50 ft (15 m) Up to 100 ft (30 m)
Nonheated and two cord heated
models
AWG 14 AWG 12
Single cord heated model AWG 12 AWG 10
Cords must be 3-conductor grounded, rated for your
environment.
