Graco REACTOR E-30 User Manual

Repair
36 309574C
Overtemperature Switch
2. Relieve pressure, page 8.
3. Wait for heaters to cool.
4. Disconnect one leadwire from overtemperature
switch (208), F
IG
. 12. Test across switch with ohm-
meter. Resistance must be approximately 0 ohms.
5. If switch fails test, cut off clamps with wire clippers.
Remove switch. Install new switch in same location
on tube (201) and secure with hose clamps (203).
Reconnect wires.
1. Turn main power OFF . Disconnect power
supply.
WARNING
Read warnings, page 6. Wait for heaters to cool before
repairing.
If wires need replacement, disconnect from tem-
perature control board. See T
ABLE
4, page 32 and
F
IG
. 10, page 33.

Graco REACTOR E-30 Specifications

General

Maximum Fluid Temperature	190°F (88°C)
Max Fluid Pressure	3000 psi
Heater Wattage	6000 W
Power Requirements	3-phase, 230V
Type	Electric
Heater Voltage	230V
Fluid Outlet Size	3/8 in
Voltage	230V
Spray Tip Size	0.015 - 0.035 in
