Graco Series A User Manual

308–626 11
Service
INJECTION HAZARD
T o reduce the risk of a serious injury ,
always follow the Pressure Relief Pro -
cedure on page 7 whenever you are
instructed to relieve the pressure.
WARNING
Swivel Kit
NOTE: Swivel Kit 238–310 contains items 7, 28, 31
and 40.
06655
8
34
40
7*{
31*{
7*{
25
16
12
30
A
29
28*{
1
6{
19
3
24
20
17{
18{
14
21
23{
22
15
35
Fig. 6
1
23{
1
2
Torque
to 20–25 ft-lb
(27–34 N Sm)
Apply anaerobic adhesive
2
