Troubleshooting
28 313289W
Paint does not cure consistently. Ratio not set correctly. Check that correct ratio is set and set by
volume. See XM sprayer operation manual.
Material not mixing correctly. Test pump. Make sure mixer is clean; flush as
needed. See XM sprayer operation manual.
Position mixer after integrator hose.
Material not properly conditioned
before it was added to sprayer.
Mix material thoroughly.
Not using enough integration hose. Add more integration hose.
Select “fast dosing” in setup.
Poor spray pattern. Fluid pressure too low. Increase pump pressure.
Fluid temperature too low. Increase fluid temperature.
Spay tip dirty or worn. Relieve pressure. Clean or replace tip. Follow
gun manual instructions.
Fluid A and B fitters plugged. Clean filters. See pump manual.
Mixer hoses partially plugged or too
restrictive.
Inspect parts for cured material. Clean or
replace, or use larger hoses and mixer.
Problem Cause Solution
