Parts
90 313289W
Primary Fluid Heater Parts
* See your Viscon HF heater manual for parts and repair.
Ref. Part Description
Qty.
240V 480V
Standard Hazardous Standard Hazardous
ABCD
51 15M987 FITTING, elbow, 60 degree
2222
53 H75003 HOSE, cpld, 7250 psi, 0.5 ID, 3 ft
3333
54 H75002 HOSE, cpld, 7250 psi, 0.5 ID, 2 ft
1111
801 C19681 BUSHING, pipe
2222
802 100840 FITTING, elbow
1111
803 551387 GAUGE, fluid pressure
2222
804* 24W248 HEATER, hf, hazardous, thermostat
2
26C476 HEATER, hf, hazardous, tstat, 240V, XMS
2
24P016 HEATER, hf, non-hazardous, tstat, 240V, XMS
2
26C475 HEATER, hf, non-hazardous, tstat, 480V, XMS
2
807 116171 BUSHING, strain relief
2 2
808 15T967 CABLE, heater, fluid, 3cond, 12 GA
2
2
809 122032 NUT, wire
4 4
810 - - - - - SEALANT, pipe, sst
1111
DOSING
VALVE
INLET
WLF
BLACK
BLACK
GREEN
WHITE
WHITE
3
+D]DUGRXV
1RQ+D]DUGRXV
PUMP
OUTLET
PUMP
OUTLET
$VLGH
$VLGH
%VLGH
%VLGH
PUMP
OUTLET
+RVHFRQQHFWLRQ
VKRZQIRUQRKHDWHUV
PUMP
OUTLET
