Dimensions
98 313289W
Dimensions
XM System Dimensions without Hoppers
(Non-Hazardous Locations)
WLD
$
%
&
'
Ref. Dimensions
A 39.5 in. 100.3 cm
B 36.0 in. 91.4 cm
C 72.5 in. 184.1 cm
D 38.0 in. 96.5 cm
