Graco XM Series

Parts
313289W 61
XM_ M _ _ Parts Varying by Top-Level Part Number
See Models, page 9, for components equipped on your system.
Model Part Description For additional information, refer to:
XM1M00
XM1A00 SYSTEM, XM50, BF, WP XM1_ _ _ Models, page 78
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
XM1M10
XM1A00 SYSTEM, XM50, BF, WP XM1_ _ _ Models, page 78
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss 10-Gallon Hopper Parts, page 92
XM1M20
XM1A00 SYSTEM, XM50, 240 V, BF, WP XM1_ _ _ Models, page 78
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V 25-Gallon Hopper Parts, page 91
XM3M00
XM3A00 SYSTEM, XM70, BF, WP XM3_ _ _ Models, page 79
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
XM3M10
XM3A00 SYSTEM, XM70, BF, WP See XM3_ _ _ Models, page 79
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss 10-Gallon Hopper Parts, page 92
XM3M20
XM3A00 SYSTEM, XM70, BF, WP XM3_ _ _ Models, page 79
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V 25-Gallon Hopper Parts, page 91
XM5M00
XM5A00 SYSTM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
XM5M0E
XM5A00 SYSTM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C899 JUNCTION BOX, standard, 240V, electric heat Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOSE, heated, electric, 240 V-H Heated Hose manual
XM5M0W
XM5A00 SYSTM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C580 JUNCTION BOX, standard, 240V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOSE, heated, watt, 240 V-H Water-Jacketed Heated Hose, page 93
XM5M10
XM5A00 SYSTEM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C580 JUNCTION BOX, standard, 240 V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss 10-Gallon Hopper Parts, page 92
XM5M1E
XM5A00 SYSTEM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C899 JUNCTION BOX, standard, 240 V, electric heat Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss 10-Gallon Hopper Parts, page 92
- - - HOSE, heated, elec, 240 V-H Heated Hose manual
XM5M1W
XM5A00 SYSTEM, XM50, BF, R, WP XM5_ _ _ Models, page 80
26C580 JUNCTION BOX, standard, 240 V Junction Box manual
- - - HEATER, standard, 240 V Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss 10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 240 V-H Water-Jacketed Heated Hose, page 93
