Graco XM Series Repair Parts

Parts
70 313289W
XM_ J_ _ Parts Varying by Top-Level Part Number
See Models, page 9, for components equipped on your system.
Model Part Description For additional information, refer to:
XM1J00
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM1J10
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM1J20
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM3J00
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM3J10
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM3J20
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM5J00
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM5J0E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C905 JUNCTION BOX, standard, 240V, electric heat
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5J0W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM5J10
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM5J1E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C905 JUNCTION BOX, haz-ex, 240 V, electric heat
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5J1W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C581 JUNCTION BOX, haz-ex, 240 V
Junction Box manual
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
