Graco XM Series Repair Parts

Parts
72 313289W
XM_ K _ _ Parts Varying by Top-Level Part Number
See Models, page 9, for components equipped on your system.
Model Part Description For additional information, refer to:
XM1K00
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
XM1K10
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM1K20
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 480 V
25-Gallon Hopper Parts, page 91
XM3K00
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
XM3K10
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM3K20
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 480 V
25-Gallon Hopper Parts, page 91
XM5K00
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
XM5K0E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C906 JUNCTION BOX, standard, 240V, electric heat
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, electric, 480 V-H
Heated Hose manual
XM5K0W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, wat, 480 V-H
Water-Jacketed Heated Hose, page 93
XM5K10
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM5K1E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C906 JUNCTION BOX, haz-ex, 480 V, electric heat
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, electric, 480 V-H
Heated Hose manual
XM5K1W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
26C583 JUNCTION BOX, haz-ex, 480 V
Junction Box manual
- - - HEATER, haz-EX, 480 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 480 V-H
Water-Jacketed Heated Hose, page 93
