Parts
313289W 81
XM7_ _ _ Models
† Must purchase when installing fluid heaters on a non-heated sprayer.
‡ Not shown.
Not assembled.
Assemble remote restrictor valve.
Ref. Part Description
XM-50 Plural Component Sprayer Models
XM7A00 XM7D00
52 117623 NUT, cap 2 2
66 L180C4 LOWER, A side; see English manual 311762 1 1
L180C3 LOWER, A side; see English manual 311762
67 L145C4 LOWER, B side; see English manual 311762 1 1
L145C3 LOWER, B side; see English manual 311762
69 17U825 LABEL, motor, A side 1 1
70 17U826 LABEL, motor, B side 1 1
76 121295 SCREW, cap, socket head 8 8
77
- - -
LABEL, system 1
- - -
LABEL, system 1
80 158491 NIPPLE; 1/2 npt 5 5
81 100361 PLUG, pipe 2 2
82 15R529 BLOCK, fluid distribution 2 2
83 156684 UNION, adapter 2 2
84 121139 O-RING; PTFE 2 2
85 15J594 HOUSING, check valve 2 2
86 15J916 HANDLE, blue 1 1
87 15R380 HANDLE, green 1 1
88 255747 CARTRIDGE, valve 2 2
89 262522 CARRIAGE, remote mix manifold 1 1
92 113796 SCREW, flanged, hex head 1 1
93 111801 SCREW, cap, hex head 8 8
94 116643 VALVE, relief; 90 psi (0.63 MPa, 6.3 bar) 1 1
100 222200 VALVE, restrictor 3 3
102
156849 PIPE, nipple; 3/8 npt 3 3
108
- - -
LABEL, XM50
- - -
LABEL, XM70 1 1
112
- - -
CABLE, CAN, IS, display to USB; female B/female B 1
116† 158683 ELBOW, 90 deg.
126 H42506 HOSE, coupled, 4500 psi
128‡
224458 STRAINER, pump; 30 mesh (qty. of 2) 1 1
152 162505 UNION, swivel; 3/8 male x 1/2 female npt 1 1
153 155699 ELBOW, street; 3/8-18 npt 1 1
154 159239 NIPPLE, pipe; 1/2 x 3/8 npt 1 1
155 164672 ADAPTER 1 1
174 16N367 COUPLING, 1/2 x 3.5 in. 1 1
