Parts
313289W 83
Control Box (255771) Parts List
Replacement safety labels, tags, and cards are
available at no cost.
‡ Not shown.
Base electronic components do not have
XM-specific software installed. Therefore, use
software upgrade token (206) to install software
before use.
† Includes software token (206) and instruction sheet.
Ref. Part Description Qty.
201 - - - BOX, control
1
202 - - - LABEL, control display
1
203† 262641 KIT, replacement, USB; includes
219 and 206
1
204 257484 MODULE, display, kit
204a 15M483 SHIELD, membrane, display
(qty. 10)
1
204b - - - SCREW, pan head; #6 x 7/8 in.
4
204c 288997 CASE, rear, display module, IS
version
1
204d 255727 CASE, front, data module
1
204e 277463 COVER, access, low level
display
1
204f 113768 SCREW, socket, flat head
4
204g 15R458 GASKET, control, front panel
1
204h 15W958 LABEL, warning, battery
1
205† 262642 KIT, replacement, display;
includes 204 and 206
1
206 17E110 TOKEN, software
1
207† 262643 KIT, replacement, FCM;
includes 218 and 206
1
208 - - - SCREW, pan head
4
209 256555 MODULE, solenoid, IS version
1
209a 121636 VALVE, solenoid, din connector
4
209b 15A798 GASKET, solenoid, outlet
1
209c 15A799 GASKET, solenoid,
inlet/exhaust
1
210 106084 SCREW, machine, pan head
2
214 15R379 GASKET, box, control
1
215 - - - LABEL
1
216‡ 15B056 LABEL, air motor/dosing valve
1
217 122000 ALARM, panel mount
1
218 255920 MODULE, fluid control
1
219 257088 MODULE, USB, assy.
219a 289899 BASE
1
219b 289900 MODULE, USB
1
219c 277674 DOOR, module
1
220 121618 SWITCH, start, push button,
green
1
221 15R324 HARNESS, USB,
plug/bulkhead; 32 in.
1
222 121619 SWITCH, stop, push button, red
1
223 121617 SWITCH, 2 position, key,
controls
1
223a‡ 123412 KEY, replacement (pair)
224 117745 BUSHING, strain relief
1
225 117625 NUT, locking
1
226 113505 NUT, keps, hex head
6
227 15B090 WIRE, grounding, door
1
228 - - - - - WASHER, lock, external
1
229 15R343 CLAMP, ground, electrical
1
230 065213 WIRE, copper, elect
3
231‡ 172953 LABEL, designation
2
232 120493 LATCH, mounting
3
233 15H189 BOOT, wire feed through
1
234 15G816 COVER, plate, wire
1
235 110637 SCREW, machine, pan head
4
236 15R325 COVER, dust, bulkhead
receptacle
1
237 120494 BLOCK, switch, n.o.
2
238 120495 BLOCK, switch, n.c.
1
239 15M974 HARNESS, key switch
1
240 15M975 HARNESS, start/alarm
1
241 15M976 HARNESS, stop
1
242 15M977 HARNESS, solenoid
2
243 121988 RETAINER, routing, wire
harness
4
244 195875 SCREW, machine, pan head
1
245 102063 WASHER, lock
1
246 17X475 CABLE, splitter
2
251 LABEL, warning, USB
1
15X214 English
15X393 All languages
252‡ 122829 CONDUIT; 0.75 ft.
-
Ref. Part Description Qty.
