Component Identification
3A3320E 7
XP-hf Proportioner (Model 572407 Shown)
WLE
,
;$
;%
;(
;'
;0
Ref. Description
XA Module
XB Housing
XD Pressure Sensors
XE Solenoid
XM Air Motor
