Gradall D152 - Left Hand Arm Pod

Section 2 - Pre-Operation and Controls
2-16 82104002
Left Hand Arm Pod
1. Boom Tilt Speed Switch: Rotary switch. Rotate switch clockwise to decrease
boom tilt speed; rotate counterclockwise to increase boom tilt speed.
2. Park Brake Switch
: See page 2-26 for details.
3. AM/FM Radio
4. Strobe Light Switch (optional): On/Off switch.
1
2
3
OAC2150
4
