Gradall D152 - Park Brake Switch

Section 2 - Pre-Operation and Controls
2-26 82104002
Park Brake Switch
• Park Brake Switch: This switch controls the application and release of the park
brake. Indicator light on the LCD display illuminates red to indicate brake is
applied.
• With the engine running and the park brake switch in “OFF” position (1), park
brake is disengaged. With switch in “ON” position (2), park brake is engaged and
transmission will not engage forward or reverse.
OAC0940
2
1
PP
View of indicator when park brake
is on. Will illuminate red.
View of indicator when
park brake is off.
OAC2200
