Section 3 - Operation
3-8 82104002
With boom positioned over front of machine:
• Reverse Travel - Press and hold the reverse travel joystick button (5). Fully
depress brake pedal (2). Transmission Gear Indicator on LCD display will
display an “R” on the left hand side of icon, indicating request for reverse gear
engagement has been made:
Transmission Gear Indicator will then display an “R” on the right hand side of
icon, indicating transmission is in gear and ready for reverse travel:
With reverse travel joystick button still depressed, release brake pedal to
begin travel. Use the travel pedal (1) to increase/decrease travel speed.
Reverse travel joystick button must remain depressed for travel.
Releasing the button during travel will engage digging brake.
UNEXPECTED TRAVEL. If on level surface, machine
will travel when transmission is engaged and brake
pedal released without any actuation of travel pedal.
• Braking - Allow travel pedal (1) to return to neutral position. Fully depress
brake pedal (2) until machine comes to a stop. Release reverse travel joystick
button (4). Digging brake will set.
