Model Name Mode String Mode P-Value
Redial redial 33
Instant message instantmessage 34
Multicast listen address multicastlistenaddress 35
Keypad Lock keypadlock 36
Table 15: VPK Modes in String Format
The string could be capital or lower-case letters, but there must be no “space” in between. For example, in the cfg.xml,
“Transfer” or “transfer” is the same as “18”, it will configure Virtual Multi-Purpose Key 3 as transfer mode.
Note: The string format is supported for MPK, extension board and softkey as well.
Figure 17: Line Key as Transfer Mode
LCD Indication and Configuration
The configured fixed VPKs are displayed next to the corresponding line. If dynamic VPKs are configured, the users can see a
page number shown on the upper left corner on the LCD.
The following figures show page 1 and page 2 of the VPKs on LCD. Pressing “RIGHT” arrow key or “Next” softkey will switch to
the next page; pressing “LEFT” arrow key will switch back to the previous page.
Figure 18: VPK – LCD Indication
Note
To Next Page
