FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 19 of 60
Upgrade protocol for firmware and configuration update. Enter
“9” to toggle between TFTP and HTTP
Firmware version information.
Firmware upgrade mode. Enter “9” to rotate among the following
three options:
1. always check
2. check when pre/suffix changes
3. never upgrade
Enter the target IP address to make a direct IP call, after dial
tone. (See “Make a Direct IP Call”.)
Phone calls between
different ports of the same
GW 400x
Applies to GXW4004/GXW4008. User can make internal calls
between different ports inside the same GW even without being
registered to SIP server. By dialing *** and 7x user can reach
colleague connected to port “x”.
Phone calls between
different ports of the same
GW4024
Applies to GXW4024. User can make internal calls between
different ports inside the same GW even without being registered
to SIP server. By dialing *** and 7xx user can reach colleague
connected to port “xx”.
Enter “9” to reboot the device; or
Enter MAC address to restore factory default setting
(See Restore Factory Default Setting section)
Automatically returns to Main Menu
Five Success Tips when using the Voice Prompt
1. “*” shifts down to the next menu option
2. “#” returns to the main menu
3. “9” functions as the ENTER key in many cases to confirm an option
4. All entered digit sequences have known lengths - 2 digits for menu option and 12 digits for IP
address. For IP address, add 0 before the digits if the digits are less than 3 (i.e. - 192.168.0.26
should be key in like 192168000026. No decimal is needed).
5. Key entry can not be deleted but the phone may prompt error once it is detected
