FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 29 of 60
CONFIGURATION GUIDE
CONFIGURING GXW40XX VIA VOICE PROMPT
DHCP MODE
Select voice menu option 01 to enable GXW40XX to use DHCP.
STATIC IP MODE
Select voice menu option 01 to enable GXW40XX to use STATIC IP mode, then use option 02, 03, 04, 05
to set up IP address, Subnet Mask, Gateway and DNS server respectively.
FIRMWARE SERVER IP ADDRESS
Select voice menu option 13 to configure the IP address of the firmware server.
CONFIGURATION SERVER IP ADDRESS
Select voice menu option 14 to configure the IP address of the configuration server.
UPGRADE PROTOCOL
Select voice menu option 15 to choose firmware and configuration upgrade protocol. User can choose
between TFTP and HTTP.
FIRMWARE UPGRADE MODE
Select voice menu option 17 to choose firmware upgrade mode among the following three options:
1) always check, 2) check when pre/suffix changes, and 3) never upgrade
WAN PORT WEB ACCESS (Note: This option is not present on GXW4024 gateway)
Select voice menu option 12 to enable WAN Port Wed Access of the device configuration pages.
CONFIGURING GXW40XX WITH WEB BROWSER
The GXW40XX series gateway has an embedded Web server that allows users to configure the
GXW40XX through a web browser.
