FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 32 of 60
G726 (16/24/32/40)
iLBC
AAL2 (all G726)
DEFINITIONS
This section will describe the options in the Web configuration user interface. As mentioned, a user can
log in as an administrator or end-user.
Functions available for the end-user are:
STATUS: Displays the network status, account status, software version and MAC-address of the
phone
BASIC SETTINGS: Basic preferences such as date and time settings, multi-purpose keys and
LCD settings can be set here.
Additional functions available to administrators are:
ADVANCED SETTINGS: To set advanced network settings, codec settings and XML
configuration settings.
PROFILE X: To configure each of the SIP accounts.
FXS PORTS: To configure each of the FXS ports and Hunting Groups etc.
TABLE 7: BASIC SETTINGS
Password to access the Web Configuration Menu. This field is case sensitive with a
maximum length of 25 characters.
By default, HTTP uses port 80. This field is for customizable web port.
There are two modes to operate the GXW40XX :
DHCP mode: The GXW40XX acquires its IP address from the first DHCP server it
discovers from the LAN It is on.
PPPoE: Set the PPPoE account settings. The GXW40XX will establish a PPPoE
session if any of the PPPoE fields is set.
Static IP mode: configure the IP address, Subnet Mask, Default Router IP address,
DNS Server 1 (primary), DNS Server 2 (secondary) fields. These fields are set to
zero by default.
