FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 36 of 60
Displays relevant information regarding the individual FXS ports. Example:
** FXS port 24 user has set Do Not Disturb.
FXS port 1 user has set his calls to be forwarded unconditionally to ext 613
FXS port 2 user has set his calls to be forwarded to 614 when his phone is busy.
FXS port 3 user is not registered with his SIP Server.
Advanced User configuration includes not only the end user configuration, but also advanced
configurations such as: SIP configuration, Codec selection, NAT Traversal Setting and other
miscellaneous configuration.
TABLE 9: ADVANCED SETTINGS
Administrator password. Only the administrator can configure the “Advanced
Settings” page. Password field is purposely left blank for security reasons after
clicking update and saved. The maximum password length is 25 characters.
This field defines the layer 3 QoS parameter which can be the value used for IP
Precedence or Diff-Serv or MPLS. Default value is 48.
Value used for layer 2 VLAN tag. Default setting is blank.
IP address or Domain name of the STUN server.
STUN server assists devices behind a NAT firewall or a router to set up calls via
VoIP.
STUN server is often provided by the VoIP service provider or a public STUN server
can be used. For a sample list of public free STUN servers please refer to:
http://www.voip-info.org/wiki-STUN
This parameter specifies the number of seconds after which a new blank UDP
packet will be sent out to the proxy/server port in order to have the port stay open
and the device remain reachable. Default is 20 seconds.
