Grandstream Networks GXW-4004 User Manual

FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 17 of 60
HARDWARE SPECIFICATION
The hardware specifications of the GXW FXS series are detailed in Table 4.
TABLE 4: HARDWARE SPECIFICATION OF GXW40XX SERIES GATEWAYS
GXW4004
GXW4008
GXW4024
Ports
4 FXS Ports
8 FXS Ports
24 FXS Ports
Network interface
1 RJ45 for LAN, 10/100
Base-TX, Full Duplex
1 RJ45 for
WAN,10/100Base-TX,
Full Duplex
1 RJ45 for LAN, 10/100
Base-TX, Full Duplex
1 RJ45 for
WAN,10/100Base-TX, Full
Duplex
1 RJ45 for LAN, 10/100 Base-
TX, Full Duplex
PSTN Port
PSTN fail-over port
PSTN fail-over port
n/a
Console
DB9 Serial port
DB9 Serial port
n/a
Universal
Switching
Power Adaptor
Input: 100-240V AC,
50/60Hz, 0.3A Max
Output: 12V DC, 1.25A
UL certified
Input: 100-240V AC,
50/60Hz, 0.3A Max
Output: 12V DC, 1.25A
UL certified
Input: 100-240V AC, 50/60Hz
Output: 12V DC, 5.0A, UL
certified
Short Haul Loop
2REN: Up to 1km on 24
AWG wire
2REN: Up to 1km on 24
AWG wire
2REN: Up to 1km on 24 AWG
wire
Mounting
Wall mount, Desktop
Wall mount, Desktop
Rack, Wall mount
Dimension
225mm (L) x 135mm (W)
x 35mm (H)
225mm (L) x 135mm (W) x
35mm (H)
445mm (L) x 269mm (W) x
44.5mm (H), or 1U
Weight
0.29 lbs (3.5 oz)
0.29 lbs (3.5 oz)
6.3 lbs (2.8 kg)
Temperature
32~104°F / 0~40°C
32~104°F / 0~40°C
32~104°F / 0~40°C
Humidity
10% - 90% (non-
condensing)
10% - 90% (non-
condensing)
10% - 90% (non-condensing)
Safety
UL
UL
UL
Compliance
FCC, CE
FCC, CE
FCC, CE, C-Tick
