FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 35 of 60
Value is set in units of hours. Default value is 120 hrs (5 Days.) The time IP
address is assigned to the LAN clients.
Note: This option is not present on GXW4024
Forward all WAN IP traffic to a specific IP address if no matching port is used by
GXW40XX or defined in port forwarding.
Note: This option is not present on GXW4024
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific
(TCP/UDP) port.
Note: This option is not present on GXW4024
In addition to the Basic Settings configuration page, end users also has access to the Device Status page.
TABLE 8: STATUS PAGE
The device ID in hexadecimal format. This is needed for Internet Service Provider
troubleshooting. Note: there are separate MAC addresses for the WAN side and the
LAN side. The LAN MAC address will be used for provisioning and can be found on the
label on original box and on the label located on the bottom panel of the device.
Shows WAN IP address of GXW40XX
Contains the product model info.
Program: This is the main software release. Boot and Loader are not changed often.
Shows system uptime since the last reboot.
Shows whether the PPPoE connection is running if connected to DSL modem.
Shows type of NAT the GXW40XX is connected to via its WAN port. It is based on
STUN protocol.
