HT812/HT814 Administration Guide
Version 1.0.9.3
Figure 10: Web HTTP Port
Web Configuration Pages Definitions
This section describes the options in the HT812/HT814 Web UI. As mentioned, you can log in as an
administrator or an end user.
 Status: Displays the system info, network status, account status, and line options.
 Basic Settings: Configures the end user level password, IP address modes, web access, time zone
settings and language.
 Advanced Settings: Configures networks, upgrading and provisioning, TR-069, security settings,
date and time, syslog, audio settings, call settings and call progress tones.
 Profile (1,2): Configures the SIP Server, SIP Registration, NAT settings, call features, ring tones.
 FXS Ports: Configures SIP accounts settings, Off hook Auto-dial.
Status Page Definitions
Table 6: Status Page Definitions
Status
MAC Address
Shows device ID in hexadecimal format. This is needed by network administrators for
troubleshooting. The MAC address will be used for provisioning and can be found on
the label on original box and on the label located on the bottom panel of the device.
Note: The device has two MAC addresses, one for the WAN port and one for the LAN
port. The MAC address located on the bottom panel of the device is the MAC address
of LAN port. The MAC address of WAN port is MAC address of LAN port +1.
Example: MAC Address: WAN - “00:0B:82:25:AF:32”, LAN - “00:0B:82:25:AF:31”.
