P a g e | 32
HT812/HT814 Administration Guide
Version 1.0.9.3
Default value is 120 hrs (5 days). The length of time the IP address is assigned to the
LAN clients. Value is set in units of hours.
This function forwards all WAN IP traffic to a specific IP address if no matching port is
used by HT812/HT814 or in the defined port forwarding.
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific
(TCP/UDP) port.
Gives the administrator the option to restore default configuration on the
HT812/HT814.
There are 3 types of factory reset:
ISP Data Reset: All VoIP related configuration (mainly everything located on FXS
page).
VoIP Data Reset: All ISP (Internet Service Provider) configuration which may
affect the IP address.
Full Reset: Both VoIP and ISP related configuration at the same time.
Note: After choosing reset type, you will have to click the reset button for it to take
effect.
Advanced Settings Page Definitions
Table 8: Advanced Settings
Defines the administrator level password to access the Advanced Web
Configuration page.
This field is case sensitive. Only the administrator can configure the
“Advanced Settings” page. Password field is purposely left blank for security
reasons after clicking update and saved.
The maximum password length is 30 characters.
Re-enter the admin password to confirm change admin password on web
GUI to avoid typo or mistakes.
Sets values for:
802.1Q/VLAN Tag. Default is 0. Valid range is 0-4094.
