P a g e | 27
HT812/HT814 Administration Guide
Version 1.0.9.3
WAN IPv4 Address
Displays assigned IPv4 address.
WAN IPv6 Address
Displays assigned IPv6 address.
Product Model
Displays product model info. Default is HT812 or HT814.
Hardware Version
Displays the hardware revision information and the part number.
Software version
 Program: Specifies Program version. This is the main firmware release
number, which is always used for identifying the software system of the
HT812/HT814.
 Bootloader: Specifies Boot version.
 Core: Specifies Core version.
 Base: Specifies Base version.
 CPE: Specifies CPE version. CPE version is displayed only when
HT812/HT814 is connected to an ACS using TR-069 protocol.
Software Status
Indicates the current software status of the HT (Running or Stopped).
System Up Time
Indicates actual system time and uptime since last reboot.
PPPoE Link Up
Indicates PPPoE connection status.
NAT
Indicates type of NAT when it is configured.
Port Status
Displays relevant information regarding the FXS ports about their registration, current
status and their appropriate User ID.
Port Options
Displays relevant information regarding the FXS ports about their DND and call forward
features.
Provision
Displays provisioning status.
Core Dump
Provides generated core dump file if unit malfunctions. Clean will be displayed if no
issues.
Basic Settings Page Definitions
Table 7: Basic Settings Page
Basic Settings
New End User
Password
Configures user level password. Case sensitive and max. length of 25 characters.
Confirm End User
Password
Re-enter the end user password to confirm change user password on web GUI to avoid
typo or mistakes.
