P a g e | 28
HT812/HT814 Administration Guide
Version 1.0.9.3
Configure timer to logout web session during idle. Default is 10 min. Range is 2-60 min.
Configure attempt limit before lockout (Default is 5. Range is 1-10).
If login attempt failed 5 times, login would be locked out for the time length. (Default 15
mins. Range 1-15 min).
Allows users to choose the Web Access Mode between “HTTPS” and “HTTP”. If
“HTTPS” is selected, web UI will be accessed using HTTPS. Default is “HTTP”.
Customizes HTTP port used to access the HT812/HT814 web UI. Default is 80.
Customizes HTTPS port used to access the HT812/HT814 web UI. Default is 443.
Enables/disables the SSH access. Default is No (disabled).
Allows users to self-configure SSH Port number. By default, the port number is 22.
Enables/disables the Telnet access. Default is Yes (disabled).
Allows users to self-configure Telnet Port number. By default, the port number is 23.
Enables / Disables the Web and SSH access through the WAN port. The available
options are the following:
No: WAN side access for the Web GUI and SSH is disabled.
Yes: WAN side access for the Web GUI and SSH is enabled.
Auto: WAN side access allowed for private IP; rejected for public IP.
Default setting is Auto.
Allows users to configure the white List for WAN Side to be used for remote
management.
Multiple IPs are supported and need to be separated by “space”.
Example: 192.168.5.222 192.168.5.223 192.168.7.0/24
Allows users to configure the black List for WAN Side to ban WAN side web access.
Multiple IPs are supported and need to be separated by “space”.
Example: 192.168.5.222 192.168.5.223 192.168.7.0/24
