HT812/HT814 Administration Guide
Version 1.0.9.3
FXS Ports Page Definitions
Table 10: FXS Ports
FXS Ports
Port
Display the port number
SIP User ID
Defines user account information provided by VoIP service provider (ITSP).
Usually in the form of digit similar to phone number or actually a phone
number.
Authenticate ID
Determines account authenticate ID provided by VoIP service provider
(ITSP). Can be identical to or different from “SIP user ID”.
Password
Specifies account password provided by VoIP service provider (ITSP) to
register to SIP servers.
Name
Chooses a name to be associated to user.
Profile ID
Defines the profile ID for each port.
Hunting Group
Configures hunting group feature on the specific port.
For example: Port 1, 2, and 3 are members of the same Hunting Group. Port
1 is registered with a SIP account.
Ports 2, and 3 are not registered. Ports 2 and 3 will be able to place outbound
calls using the SIP account of port 1. Select appropriate value for Hunting
Group feature.
The original SIP account should be set to Active while the group members
should be set to the port number of the Active Port.
Example configuration of a Hunting group:
FXS Port #1: SIP UserID and Authenticate ID entered, Hunting group set to
"Active"
FXS Port #2: SIP UserID and Authenticate ID left blank, Hunting Group set to
"1"
FXS Port #3: SIP UserID and Authenticate ID left blank, Hunting Group set to
"1"
FXS Port #4: SIP UserID and Authenticate ID entered, Hunting group set to
"None"
Hunting Group 1 contains ports 1, 2, 3. FXS port 4 is registered but it is not
added to the Hunting Group 1
