HT818 Administration Guide
Version 1.0.27.2
Figure 3: Connecting the HT818
HT818 LEDs Pattern
There are four (4) LED types that help you manage the status of your HT818.
Table 4: HT818 LEDs Pattern Description
LED Lights
Status
Power LED
The Power LED lights up when The HT818 is powered on and it flashes
when the HT818 is booting up
WAN LED
The WAN LED lights up when The HT818 is connected to your network
through the WAN port.
LAN LED
The LAN LED lights up when The HT818 is connected to your network
through the LAN port.
Phone LED 1- 8
The phone LEDs indicate status of the respective FXS port-phone on the
back panel
• OFF - Unregistered
• ON (Solid Blue) - Registered and Available
• Blinking every 500 ms - Off-Hook / Busy
• Slow blinking - FXS LEDs indicates voicemail
Figure 4: HT818 LEDs Pattern
