Grandstream Networks HT818 Administration Guide

P a g e | 26
HT818 Administration Guide
Version 1.0.27.2
• FXS Ports: Configures SIP accounts settings, Off hook Auto-dial.
Status Page Definitions
Table 6: Status Page Definitions
Status
MAC Address
Shows device ID in hexadecimal format. This is needed by network administrators
for troubleshooting. The MAC address will be used for provisioning and can be
found on the label on original box and on the label located on the bottom panel of
the device.
Note: The device has two MAC addresses, one for the WAN port and one for the
LAN port. The MAC address located on the bottom panel of the device is the MAC
address of LAN port. The MAC address of WAN port is MAC address of LAN port
+1.
Example: MAC Address: WAN - “00:0B:82:25:AF:32”, LAN - “00:0B:82:25:AF:31”.
WAN IPv4 Address
Displays assigned IPv4 address.
WAN IPv6 Address
Displays assigned IPv6 address.
Product Model
Displays product model info. Default is HT818.
Hardware Version
Displays the hardware revision information and the part number.
Software version
• Program: Specifies Program version.
This is the main firmware release number, which is always used for
identifying the software system of the HT818.
• Bootloader: Specifies Boot version.
• Core: Specifies Core version.
• Base: Specifies Base version.
• CPE: Specifies CPE version. CPE version is displayed only when HT818
is connected to an ACS using TR-069 protocol.
Software Status
Indicates the current software status of the HT (Running or Stopped).
System Up Time
Indicates actual system time and uptime since last reboot.
CPU Load
Indicates CPU load (%)
Network Cable Status
Indicates status of the cable (Up/Down) and speed information of the connection
(Full/Half).
Up/Down means cable connected/disconnected.
Full/Half means full duplex/half duplex.
